SSM-118-L-DH
Manufacturer
Samtec
Description
PCB Receptacle, Board-to-Board, 2.54 mm, 2 Rows, 36 Contacts, Surface Mount Right Angle
Datasheet
DownloadProduct Attributes
Type
Color
Connector Type
Contact Material
Contact Plating
Contact Resistance
Depth
Gender
Housing Color
Lead Free
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Min Operating Temperature
Mount
Number of Contacts
Number of Positions
Number of Rows
Orientation
Pitch
REACH SVHC
RoHS
Row Spacing
Termination
Width
Description
Black
Receptacle, Socket
Bronze
Gold
10 mΩ
11.18 mm
Receptacle
Black
Lead Free
45.72 mm
Production (Last Updated: 3 years ago)
PRODUCTION (Last Updated: 3 years ago)
6.9 A
125 °C
450 V
-55 °C
Surface Mount
36
36
2
Right Angle
2.54 mm
No
Compliant
2.54 mm
Solder
8.13 mm
₹773.17
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹773.17
₹773.17
10
₹773.72
₹7737.24
25
₹773.76
₹19344.01
