TC4049BF-ELNF
Manufacturer
Toshiba
Description
Inverter, 4000/14000/40000 Series, 6-Func, 1-Input, CMOS, PDSO16
Datasheet
DownloadProduct Attributes
Type
Case/Package
Height - Seated (Max)
High Level Output Current
Length
Lifecycle Status
Load Capacitance
Logic Function
Low Level Output Current
Max Operating Temperature
Max Power Dissipation
Max Supply Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Number of Circuits
Number of Input Lines
Number of Inputs
Number of Output Lines
Number of Pins
Number of Terminals
Operating Supply Voltage
Output Type
Polarity
Propagation Delay
Quiescent Current
RoHS
Schmitt Trigger Input
Terminal Pitch
Turn-On Delay Time
Width
Description
SOP
1.9 mm
48 mA
10.3 mm
Production (Last Updated: 9 months ago)
50 pF
Buffer, Inverter
8 mA
85 °C
180 mW
18 V
-40 °C
3 V
Surface Mount
6
6
1
6
16
16
5 V
TTL
Inverting
120 ns
4 µA
Compliant
No
1.27 mm
30 ns
5.3 mm
₹131.76
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹131.76
₹131.76
10
₹80.34
₹803.37
25
₹66.90
₹1672.62
50
₹66.90
₹3345.24
100
₹51.70
₹5169.75
500
₹39.60
₹19801.51
1000
₹32.60
₹32596.88
