TIP47
Manufacturer
STMicroelectronics
Description
Power Bipolar Transistor, 1A I(C), 1-Element, NPN, Silicon, TO-220AB, Plastic/Epoxy, 3 Pin
Datasheet
DownloadProduct Attributes
Type
Case/Package
Collector Base Voltage (VCBO)
Collector Emitter Breakdown Voltage
Collector Emitter Saturation Voltage
Collector Emitter Voltage (VCEO)
Current Rating
Element Configuration
Emitter Base Voltage (VEBO)
Frequency
Gain Bandwidth Product
Height
hFE Min
Lead Free
Length
Lifecycle Status
Max Collector Current
Max Frequency
Max Operating Temperature
Max Power Dissipation
Min Operating Temperature
Mount
Number of Elements
Number of Pins
Polarity
Power Dissipation
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Transition Frequency
Weight
Width
Description
TO-220
350 V
250 V
1 V
250 V
1 A
Single
5 V
10 MHz
10 MHz
15.75 mm
30
Lead Free
10.4 mm
Production (Last Updated: 4 years ago)
1 A
10 MHz
150 °C
40 W
-65 °C
Through Hole
1
3
NPN
2 W
No
No
Compliant
8541290080
10 MHz
9.071847 g
4.6 mm
₹116.90
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹116.90
₹116.90
10
₹47.29
₹472.94
25
₹47.29
₹1182.35
50
₹47.29
₹2364.70
100
₹41.88
₹4187.98
500
₹34.85
₹17424.95
1000
₹30.77
₹30773.20
