TLV1117-50IDCY
Manufacturer
Texas Instruments
Description
800-mA, 15-V, linear voltage regulator 4-SOT-223 -40 to 125
Datasheet
DownloadProduct Attributes
Type
Accuracy
Case/Package
Dropout Voltage
Height
Input Bias Current
Lead Free
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Input Voltage
Max Junction Temperature (Tj)
Max Operating Temperature
Max Output Current
Max Supply Voltage
Min Current Limit
Min Input Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Nominal Output Voltage
Nominal Supply Current
Number of Channels
Number of Outputs
Number of Pins
Number of Regulators
Output Current
Output Type
Output Voltage
Polarity
Quiescent Current
Radiation Hardening
REACH SVHC
Reference Voltage
RoHS
Thickness
Width
Description
3.75 %
SOT-223
1.2 V
1.8 mm
5 mA
Lead Free
6.5 mm
Production (Last Updated: 1 week ago)
ACTIVE (Last Updated: 1 week ago)
15 V
125 °C
125 °C
800 mA
15 V
800 mA
6.4 V
-40 °C
6.4 V
Surface Mount
5 V
5 mA
1
1
4
1
800 mA
Fixed
5 V
Positive
15 mA
No
No
5.2 V
Compliant
1.6 mm
3.5 mm
In Stock
Quantity
MOQ : 2
Per Unit Price
₹82.70
Total Price
₹165.39
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹165.39
₹165.39
10
₹59.58
₹595.76
25
₹59.51
₹1487.63
50
₹47.89
₹2394.62
100
₹45.12
₹4511.80
500
₹43.04
₹21519.08
1000
₹41.49
₹41489.18
