TPD4E004DRYR
Manufacturer
Texas Instruments
Description
Quad 1.6-pF, 5.5-V, 8-kV ESD protection diode with VCC pin for High Speed Interfaces 6-SON -40 to 85
Datasheet
DownloadProduct Attributes
Type
Breakdown Voltage
Capacitance
Depth
Direction
Height
Interface
Lead Free
Leakage Current
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Operating Temperature
Max Supply Voltage
Min Breakdown Voltage
Min Operating Temperature
Min Supply Voltage
Number of Bidirectional Channels
Number of Channels
Number of Pins
Operating Supply Voltage
Power Line Protection
Radiation Hardening
REACH SVHC
Reverse Standoff Voltage
RoHS
Schedule B
Termination
Thickness
Width
Description
6 V
2 pF
1.05 mm
Unidirectional
600 µm
Ethernet, USB
Lead Free
1 nA
1.45 mm
Production (Last Updated: 5 days ago)
ACTIVE (Last Updated: 5 days ago)
85 °C
5.5 V
6 V
-40 °C
900 mV
4
4
6
800 mV
Yes
No
No SVHC
5.5 V
Compliant
8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080
SMD/SMT
500 µm
1 mm
In Stock
Quantity
MOQ : 2
Per Unit Price
₹55.13
Total Price
₹110.26
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹110.26
₹110.26
10
₹43.84
₹438.38
25
₹43.84
₹1095.94
50
₹43.84
₹2191.88
100
₹30.94
₹3093.53
500
₹24.10
₹12052.22
1000
₹20.48
₹20478.28
