TQ2SA-L2-5V
Manufacturer
Panasonic
Description
Electromechanical Relay 5VDC 178Ohm 2A DPDT (14x11.5x5.6)mm SMD General Purpose Relay
Datasheet
DownloadProduct Attributes
Type
Ambient Temperature Range High
Approvals
Coil Current
Coil Power
Coil Resistance
Coil Type
Coil Voltage (DC)
Contact Current Rating
Contact Material
Contact Plating
Contact Resistance
Contact Voltage Rating (AC)
Current Rating
Depth
Electrical Life
Height
Insertion Loss (dB)
Insulation Resistance
Lead Free
Lead Pitch
Length
Lifecycle Status
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Min Operating Temperature
Mount
Number of Contacts
Number of Pins
Number of Poles
Number of Terminals
Operate Time
Pitch
Power Consumption
Radiation Hardening
Ratings
REACH SVHC
Relay Type
Release Time
Response Time
RoHS
Switching Current
Switching Voltage
Termination
Test Voltage
Throw Configuration
Voltage Rating (AC)
Voltage Rating (DC)
Weight
Width
Description
85 °C
CSA, UL
28 mA
140 mW
178 Ω
Latching, Dual Coil
3.75 V
2 A
Silver
Gold
75 mΩ
125 V
2 A
11.5 mm
100 kcycles
5.4 mm
0.8 dB
1 GΩ
Lead Free
2.54 mm
14 mm
Production (Last Updated: 7 months ago)
2 A
70 °C
125 V
220 V
-40 °C
PCB, Surface Mount
2
10
2
10
4 ms
2.54 mm
140 mW
No
IP67
Yes
Telecom
4 ms
4 ms
Compliant
2 A
220 V
Gull Wing
1.5 kV
DPDT
125 V
220 V
2 g
9 mm
In Stock
Quantity
MOQ : 1
Per Unit Price
₹466.83
Total Price
₹466.83
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹466.83
₹466.83
10
₹413.74
₹4137.45
25
₹413.83
₹10345.84
50
₹285.82
₹14291.22
100
₹283.71
₹28370.81
500
₹268.77
₹134387.46
1000
₹268.77
₹268774.93
