TS5A23157RSER
Manufacturer
Texas Instruments
Description
5-V, 2: 1 (SPDT), 2-channel analog switch 10-UQFN -40 to 125
Datasheet
DownloadProduct Attributes
Type
-3db Bandwidth
Ambient Temperature Range High
Bandwidth
Case/Package
Contact Plating
Drain to Source Resistance
Height
High Level Output Current
Lead Free
Length
Lifecycle Status
Low Level Output Current
Manufacturer Lifecycle Status
Max Junction Temperature (Tj)
Max Operating Temperature
Max Supply Current
Max Supply Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Nominal Supply Current
Number of Channels
Number of Circuits
Number of Inputs
Number of Outputs
Number of Pins
On-State Resistance
Operating Supply Current
Polarity
Radiation Hardening
REACH SVHC
RoHS
Schedule B
Supply Type
Termination
Thickness
Throw Configuration
Turn-Off Delay Time
Turn-On Delay Time
Weight
Width
Description
220 MHz
125 °C
220 MHz
QFN
Gold
10 Ω
600 µm
50 mA
Lead Free
1.5 mm
Production (Last Updated: 2 months ago)
50 mA
ACTIVE (Last Updated: 2 months ago)
150 °C
125 °C
10 µA
5.5 V
-40 °C
1.65 V
Surface Mount
1 µA
2
2
2
4
10
10 Ω
1 µA
Non-Inverting
No
No
Compliant
8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000
Single
SMD/SMT
550 µm
SPDT
3.8 ns
5.7 ns
7.002332 mg
2 mm
In Stock
Quantity
MOQ : 2
Minimum Qty : 2
Per Unit Price
₹71.40
Total Price
₹142.81
Ships in 7-10 days from Bengaluru
Quantity
Unit Price
Ext. Price
1
₹141.92
₹141.92
10
₹50.38
₹503.82
25
₹45.24
₹1130.92
50
₹45.24
₹2261.85
100
₹38.83
₹3883.29
500
₹35.18
₹17589.21
1000
₹28.94
₹28938.38
