UPD78F0433GB-GAG-AX
Manufacturer
Renesas
Description
Compact, Low-power 8-bit Microcontrollers for Applications Using LCD Display (Non Promotion)
Datasheet
DownloadProduct Attributes
Type
Case/Package
China RoHS
Clock Rate
Core Architecture
Data Bus Width
Density
EEPROM Memory Size
Frequency
Height
Interface
Length
Lifecycle Status
Manufacturer Lifecycle Status
Max Frequency
Max Input Voltage
Max Operating Temperature
Max Supply Current
Max Supply Voltage
Memory Size
Memory Type
Min Input Voltage
Min Operating Temperature
Min Supply Voltage
Mount
Number of Bits
Number of I2C Channels
Number of I/Os
Number of Pins
Number of Programmable I/O
Number of PWM Channels
Number of SPI Channels
Number of Terminals
Number of Timers/Counters
Number of UART Channels
Operating Supply Voltage
Oscillator Type
Peripherals
Radiation Hardening
RAM Size
REACH SVHC
RoHS
Terminal Pitch
Termination
Watchdog Timer
Width
Description
LQFP
Compliant
10 MHz
78K0
8 b
256 kb
0 B
10 MHz
1.6 mm
LIN, UART, USART
10 mm
NRND (Last Updated: 4 months ago)
NOT RECOMMENDED FOR NEW DESIGNS (Last Updated: 4 months ago)
20 MHz
5.5 V
85 °C
3.4 mA
5.5 V
32 kB
FLASH
1.8 V
-40 °C
2.7 V
Surface Mount
8
0
34
52
30
3
1
52
7
2
3 V
External
LCD, LVD, POR, PWM, WDT
No
1 kB
Yes
Compliant
635 µm
SMD/SMT
Yes
10 mm
In Stock
Quantity
MOQ : Unavailable
Per Unit Price
₹Infinity
Total Price
₹Infinity
Ships in 7-10 days from Bengaluru
