UUP1H0R1MCL1GS
Manufacturer
Nichicon
Description
0.1 F 50 V Aluminum Electrolytic Capacitors Radial, Can - SMD 1000 Hrs @ 105C
Datasheet
DownloadProduct Attributes
Type
Capacitance
Tolerance
Voltage - Rated
Lifetime @ Temp.
Max Operating Temperature
Polarization
Ratings
Applications
Ripple Current (AC)
Ripple Current @ High Frequency
Size / Dimension
Height - Seated (Max)
Surface Mount Land Size
Mounting Type
Case/Package
Description
0.1 µF
±20%
50 V
1000 Hrs @ 105°C
-55°C ~ 105°C
Bi-Polar
AEC-Q200
General Purpose
1 mA @ 120 Hz
1.5 mA @ 10 kHz
0.157" Dia (4.00mm)
0.240" (6.10mm)
0.169" L x 0.169" W (4.30mm x 4.30mm)
Surface Mount
Radial, Can - SMD
₹104.51
In Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹104.51
₹104.51
10
₹58.12
₹581.22
25
₹58.12
₹1453.05
50
₹49.96
₹2497.95
100
₹44.48
₹4447.52
500
₹35.67
₹17834.26
1000
₹32.81
₹32814.64
Product Attributes
Type
Capacitance
Tolerance
Voltage - Rated
Lifetime @ Temp.
Max Operating Temperature
Polarization
Ratings
Applications
Ripple Current (AC)
Ripple Current @ High Frequency
Size / Dimension
Height - Seated (Max)
Surface Mount Land Size
Mounting Type
Case/Package
Description
0.1 µF
±20%
50 V
1000 Hrs @ 105°C
-55°C ~ 105°C
Bi-Polar
AEC-Q200
General Purpose
1 mA @ 120 Hz
1.5 mA @ 10 kHz
0.157" Dia (4.00mm)
0.240" (6.10mm)
0.169" L x 0.169" W (4.30mm x 4.30mm)
Surface Mount
Radial, Can - SMD
