YB25KKW01-6G-JB
Manufacturer
NKK Switches
Description
Switch, P/b, DPDT, On-(on), Sq, 3.6V Sb Blue Led, Clear/white Cap, 3A, 125VAC, .110" Qc
Datasheet
DownloadProduct Attributes
Type
Contact Material
Contact Plating
Current Rating
Depth
Electrical Life
Flammability Rating
Housing Material
Illumination Color
Illumination Type
Length
Life (Cycles)
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Mechanical Life
Min Operating Temperature
Mount
RoHS
Switch Function
Termination
Throw Configuration
Voltage Rating (AC)
Voltage Rating (DC)
Description
Silver
Silver
3 A
18 mm
100 kcycles
UL94 V-0
Polyamide
Blue
LED
18 mm
1 Mcycles
3 A
50 °C
250 V
30 V
1 Mcycles
-25 °C
Panel, Snap-In
Compliant
On-Mom
Solder
DPDT
125 V
30 V
₹3508.11
Out of Stock
Ships in 7-10 days
Quantity
Unit Price
Ext. Price
1
₹3508.11
₹3508.11
10
₹3484.59
₹34845.94
25
₹3484.61
₹87115.32
50
₹3414.38
₹170718.87
100
₹3358.40
₹335839.77
500
₹3358.40
₹1679197.94
1000
₹3311.20
₹3311202.92
Product Attributes
Type
Contact Material
Contact Plating
Current Rating
Depth
Electrical Life
Flammability Rating
Housing Material
Illumination Color
Illumination Type
Length
Life (Cycles)
Max Current Rating
Max Operating Temperature
Max Voltage Rating (AC)
Max Voltage Rating (DC)
Mechanical Life
Min Operating Temperature
Mount
RoHS
Switch Function
Termination
Throw Configuration
Voltage Rating (AC)
Voltage Rating (DC)
Description
Silver
Silver
3 A
18 mm
100 kcycles
UL94 V-0
Polyamide
Blue
LED
18 mm
1 Mcycles
3 A
50 °C
250 V
30 V
1 Mcycles
-25 °C
Panel, Snap-In
Compliant
On-Mom
Solder
DPDT
125 V
30 V
